Pipe Clips for ASTM Pipes
As Per ASTM D-2467
To fix and secure the pipeline to a wall or a flat surface.
Dimensions of Clip for Pipe Fittings
| Size (mm) |
Size (Inch) |
L | a | e (min) |
Material Code | Standard Pkg. |
| 15 | ½” | 16.00 | 38.50 | 2.50 | 4643 | 300 |
| 20 | ¾” | 19.50 | 43.00 | 2.50 | 4644 | 1000 |
| 25 | 1” | 24.00 | 51.00 | 3.50 | 4645 | 800 |
| 32 | 1¼” | 30.00 | 60.00 | 3.50 | 4646 | 250 |
| 40 | 1½” | 39.00 | 67.60 | 4.50 | 4647 | 250 |
| 50 | 2” | 46.00 | 78.00 | 4.50 | 4648 | 75 |
| 65 | 2½” | 72.20 | 102.00 | 3.00 | 4649 | 100 |
| 80 | 3” | 74.50 | 115.00 | 3.00 | 4650 | 88 |
| 100 | 4” | 90.00 | 132.00 | 3.50 | 4651 | 60 |
| * All dimensions in "MM" |
