Agricultural Ring Fit PVC-U Pipe
Conforming to IS 4985
Our first in India Agricultural Ring Fit PVC-U Pipes offer reliable and efficient solutions for high-diameter irrigation needs. Engineered for efficiency and reliability, these PVC ring pipes cut down the need for solvent cement, ensuring seamless performance under challenging conditions. Built for durability, they represent the ideal choice for modern agricultural systems.
-
Innovative DesignRing-Fit PVC pipes simplify installation without the need for solvent cement.
-
Large DiameterSpecially designed to meet high-diameter requirements for agricultural applications.
-
High PerformanceThese PVC-U Ring-Fit pipes ensure durability and efficiency across various pressure classes.
-
Versatile ApplicationsSuitable for irrigation systems requiring reliable and robust connections.
-
Reliable SolutionThe PVC Ring pipes are easy to use and durable, making them a trusted choice for modern farmin
Dimensions of PVC-U Ringfit Agriculture Pipes
| DIMENSIONS OF RINGFIT PVC-U PIPES CONFORMING TO: IS 4985 | ||||||||||||||||||||||
| Nominal Outside Diameter “D” | Mean Outside Diameter (mm) | Wall Thickness (mm) | Material Code | Std. Pipe Length |
||||||||||||||||||
| Class 1 0.25 Mpa |
Class 2 0.40 Mpa |
Class 3 0.60 Mpa |
Class 4 0.80 Mpa |
Class 5 1.00 Mpa |
Class 6 1.25 Mpa |
Class 1 0.25 Mpa |
Class 2 0.40 Mpa |
Class 3 0.60 Mpa |
Class 4 0.80 Mpa |
Class 5 1.00 Mpa |
Class 6 1.25 Mpa |
|||||||||||
| mm | inch | min | max | min | max | min | max | min | max | min | max | min | max | min | max | meter | ||||||
| 63 | 2" | 63.0 | 63.3 | - | - | 1.5 | 1.9 | 2.2 | 2.7 | 2.8 | 3.3 | 3.5 | 4.1 | 4.3 | 5.0 | - | 1213 | 1214 | 1215 | 1216 | 1217 | 6 |
| 75 | 2.1/2" | 75.0 | 75.3 | - | - | - | - | 2.6 | 3.1 | - | - | - | - | - | - | - | - | 1218 | - | - | - | 3 |
| 75 | 2.1/2" | 75.0 | 75.3 | - | - | 1.8 | 2.2 | 2.6 | 3.1 | 3.4 | 4.0 | 4.2 | 4.9 | 5.1 | 5.9 | - | 1219 | 1220 | 1221 | 1222 | 1223 | 6 |
| 90 | 3" | 90.0 | 90.3 | - | - | 2.1 | 2.6 | 3.1 | 3.7 | 4.0 | 4.6 | 5.0 | 5.7 | 6.1 | 7.1 | - | 1224 | 1225 | 1226 | 1227 | 1228 | 6 |
| 110 | 4" | 110.0 | 110.4 | - | - | - | - | 3.7 | 4.3 | - | - | - | - | - | - | - | - | 1229 | - | - | - | 3 |
| 110 | 4" | 110.0 | 110.4 | - | - | 2.5 | 3.0 | 3.7 | 4.3 | 4.9 | 5.6 | 6.1 | 7.1 | 7.5 | 8.7 | - | 1230 | 1231 | 1232 | 1233 | 1234 | 6 |
| 125 | 4.1/2" | 125.0 | 125.4 | - | - | 2.9 | 3.4 | 4.3 | 5.0 | 5.6 | 6.4 | 6.9 | 8.0 | 8.5 | 9.8 | - | 1235 | 1236 | 1237 | 1238 | 1239 | 6 |
| 140 | 5" | 140.0 | 140.5 | - | - | 3.2 | 3.8 | 4.8 | 5.5 | 6.3 | 7.3 | 7.7 | 8.9 | 9.5 | 11.0 | - | 1240 | 1241 | 1242 | 1243 | 1244 | 6 |
| 160 | 6" | 160.0 | 160.5 | - | - | 3.7 | 4.3 | 5.4 | 6.2 | 7.2 | 8.3 | 8.8 | 10.2 | 10.9 | 12.6 | - | 1245 | 1246 | 1247 | 1248 | 1249 | 6 |
| 180 | 7" | 180.0 | 180.6 | 2.6 | 3.1 | 4.2 | 4.9 | 6.1 | 7.1 | 8.0 | 9.2 | 9.9 | 11.4 | - | - | 1250 | 1251 | 1252 | 1253 | 1254 | - | 6 |
| 200 | 8" | 200.0 | 200.6 | 2.9 | 3.4 | 4.6 | 5.3 | 6.8 | 7.9 | 8.9 | 10.3 | 11.0 | 12.7 | - | - | 1255 | 1256 | 1257 | 1258 | 1259 | - | 6 |
| 225 | 9" | 225.0 | 225.7 | 3.3 | 3.9 | 5.2 | 6.0 | 7.6 | 8.8 | 10.0 | 11.5 | 12.4 | 14.3 | - | - | 1260 | 1261 | 1262 | 1263 | 1264 | - | 6 |
| 250 | 10" | 250.0 | 250.8 | 3.6 | 4.2 | 5.7 | 6.5 | 8.5 | 9.8 | 11.2 | 12.9 | 13.8 | 15.9 | - | - | 1265 | 1266 | 1267 | 1268 | 1269 | - | 6 |
| 280 | 11" | 280.0 | 280.9 | 4.1 | 4.8 | 6.4 | 7.4 | 9.5 | 11.0 | 12.5 | 14.4 | 15.4 | 17.8 | - | - | 1270 | 1271 | 1272 | 1273 | 1274 | - | 6 |
| 315 | 12" | 315.0 | 316.0 | 4.6 | 5.3 | 7.2 | 8.3 | 10.7 | 12.4 | 14.0 | 16.1 | 17.3 | 19.9 | - | - | 1275 | 1276 | 1277 | 1278 | 1279 | - | 6 |
| 355 | 14" | 355.0 | 356.1 | 5.1 | 5.9 | 8.1 | 9.4 | 12.0 | 13.8 | 15.8 | 18.2 | 19.6 | 22.6 | - | - | 1280 | 1281 | 1282 | 1283 | 1284 | - | 6 |
| 400 | 16" | 400.0 | 401.2 | 5.8 | 6.7 | 9.1 | 10.5 | 13.5 | 15.6 | 17.8 | 20.5 | 22.0 | 25.3 | - | - | 1285 | 1286 | 1287 | 1288 | 1289 | - | 6 |
| Batch number logic: | ||||||||||||||||||||||
| Year | Month | Day | M/C No. | Shift | ||||||||||||||||||
| xxxx | xx | xx | xxx | x | ||||||||||||||||||
| For example, the batch number of pipes produced on Mc. no. 20 | ||||||||||||||||||||||
| on 1st June 2021 in the 1st shift will be 202106010201 | ||||||||||||||||||||||
Related Products
FAQ's
-
Can ring-fit pipes be used for both above-ground and underground installations?
Yes, ringfit pipes can be used both in-ground and above-ground. Their ability to accommodate soil shifts and land contours, up to 2 degrees per joint, makes them suitable for underground installations, while their durable design also supports above-ground applications.
-
Are there specific installation requirements for ring-fit pipes?
Yes, proper mounting of the rubber ring and application of lubricant are essential for installing ring-fit pipes.
-
Are ring-fit pipes compatible with existing piping systems?
Yes, ring-fit pipes are compatible with most standard plumbing systems and are available in various sizes to accommodate different plumbing needs.
